青龍系列
  • 編號：MT-024
  • 商品瓦數：70W~100w ； 120W~200w
  • 適用範圍：天井燈、路燈
產 品 介 紹
恆日﹝青龍系列﹞(Lighten Dragon Series)
為一結合高島熱(銅基板)、高信賴性、寬可視角、COB多晶封裝、易組裝、無暗區。
專為天井燈、路燈等面光源燈具所設計之高效模組。

Lighten Dragon Series
A highest performance LED module design for Genral Lighting application, with highest system thermal conductivity、higher reliability、wide view angle、multichip COB package.

By our product you can reduce the overall fixture labeling cost no dark zone, and
good for High Bay or streelight...wit the higher lumens and longer life fixture applications
產品規格 / Specifications
青龍系列
Dragon Series
Sutstrata size (mm) Powar(w) Drive current(A) Max current(A) Forward voltaga(v)
x y
LTCX1113-070-001 65 65 70 1.928 2,12 3.63
LTCX1115-080-001 65 65 80 2.204 2.42 3.63
LTCX1117-090-001 65 65 90 2.479 2.73 3.63
LTCX1119-100-002 65 65 100 2.755 3.03 3.63
LTCX1122-120-002 65 65 120 3.306 3.64 3.63
LTCX1117-150-001 65 65 150 4.132 5.95 3.63
LTCX1120-180-001 65 65 180 4.959 7.00 3.63
LTCX1122-200-001 65 65 200 5.510 7.70 3.63
