| 產品規格 |
 |
| Specification |
GH-40G |
GH-25G |
GH-20G |
GH-18G |
| Chemical Composition |
C>0.85% P<0.05% S<0.05% |
| Hardness |
63-67HRC 780-900HV |
| Microstructure |
Fine Temper Martensite |
| Sieve(mm) |
1.70 |
|
|
|
All pass |
| 1.40 |
|
|
All pass |
<30% |
| 1.18 |
|
All pass |
|
|
| 1.00 |
All pass |
|
>45% |
>70% |
| 0.85 |
|
>65% |
>85% |
>90% |
| 0.71 |
>55% |
>90% |
|
|
| 0.60 |
>90% |
|
|
|
| Nominal Size |
|
0.70mm |
0.85mm |
1.00mm |
1.15mm |
|
| Special requirements are available. |
|
 |
|
|
|
|
|
|
|
|
|
